DINITROL 520 - CHARACTERISTICS
The glass activator DINITROL 520 is a solvent containing adhesion promoting formulation which is used in combination with the DINITROL 530 for the direct glazing in the automotive industry.
In combination with the multiprimer DINITROL 550, the activator DINITROL 520 improves the adhesion on several metals and plastics. Test with actual substrates and conditions have to be preformend to ensure adhesion and material compatibility. Trials by the supplier are recommended. Product benefits are:
Pre-treatment on glasses
Pre-treatment on metals and plastics
Cleaning agent of the bonding areas
FEATURES
Cleaning agent of the bonding areas
Excellent adhesion promoter on metal & plastics (together with DINITROL 550 Multiprimer) or for the direct glazing of windscreens (with DINITROL 530)
Supports the long-term safety of replaced windscreens by DINITROL adhesives
METHOD OF USE
The activator DINITROL 520 should be applied by the wipe on/wipe off procedure. In the first step the activator should be wiped on the glass-ceramic surface of the windshield by a tissue wetted with the activator. In a second step a residual excess on the surface should be taken off by wiping with a clean tissue. Due to its reactivity with moisture, the opened bottle has to be used within a few days. After this time, or if the DINITROL 520 has become milky instead of clear, the product must be discarded. An inactivity of the activator is possible. This product is suitable for experienced professional users only.
SAFETY PRECAUTIONS
According to 1907/2006 EC, the activator DINITROL 520 must be labeled: Symbol: F, Storage between 0 and 35°C, in closed packaging in a dry and ventilated area.
TECHNICAL DATA
Chemical Base alcoholic solvents adhesion promoter
Colour transparent
Drying time approx. 5 Min.*
Viscosity Brookfield 1 – 5 Pas
Density, 23°C 800 ± 30 kg/m³
Application method tissue/paper
Application temperature + 5°C – 40°C
Flash point < 21°C
Flash-off time min. 10 minutes*
Coverage max. 24 hours
Approx. 50 g/m²
Shelf life 12 months
Available in 30 ml bottle, 250 ml bottle, 1 L bottle
DINITROL 530 - CHARACTERISTICS
DINITROL 530 is a solvent containing, physically and chemically drying black primer which promotes the adhesion between the glass (in combination with the activator DINITROL 520) and paint and the direct glazing adhesive and acts as a UV protection.
DINITROL 530 combines the following functions:
Pre-treatment on glass and paint
Inhibits rust in small nicks and scratches
Compatible with all DINOL adhesive systems
FEATURES
Primer as adhesion promoter, corrosion & UV protector, activator in combination with DINITROL 520
Excellent adhesion promoter
Supports long term safety by the use of the DINITROL adhesive system
METHOD OF USE
Before use of the primer DINITROL 530 shake the bottle thoroughly until paint mixing balls rattles freely. Mix for an additional one minute. The application of the primer DINITROL 530 can be done manually by felt and/or an adequate tool. Due to its reactivity with moisture, the opened bottle has to be used within a few days. (Recommendation: 1 week)
This product is suitable for experienced professional users only
SAFETY PRECAUTIONS
According to 1907/2006 EC, the primer DINITROL 530 is mandatory: Symbol: F, Xn Storage between 0 and 35°C, in closed packaging in a dry and ventilated area.
TECHNICAL DATA
Chemical base Reactive polyurethane adducts
Colour black liquid
Drying time approx 5 min*
Solid content 33 ± 2%
Viscosity Brookfield 17 – 25 mPas
Density, 23 °C 990 ± 20 kg/m³
Application method felt / brush
Application temperature + 5°C – 40°C
Flash point < 21°C
Flash-off time min. 10 minutes*
max. 72 hours
Coverage approx 150 g/m²
Shelf life 12 months
Available in 30 ml bottle, 100 ml bottle, 250 ml bottle, 1 L bottle
